通过压力传感器安装实时监控压力
好产品形号 | VIC-D210 | VIC-D220 | VIC-D240 | VIC-D245 |
的流量量限(N2基准面) | 5~1,500 sccm | 1.5~50 slm | 50~200 slm | 100~400 slm |
用户量检验使用范围 | 2~100% of Full Scale | |||
校正精密度 | ≤±1.0% of Full Scale | |||
初始化失败周期 | ≤ 1 sec | |||
直平滑 | ≤±0.2% of Full Scale | |||
复现性 | ≤±0.2% of Full Scale | |||
操纵阀分类 | Normally Closed Solenoid | |||
密封胶面料 | Elastomer (Viton®, Viton-ETP®, Kalrez®, PTFE, etc.) | |||
数码插口 | RS-485 | |||
信号灯业务类型 | Analog Mode : 0~5VDC or 4~20mA Digital Mode : RS-485 | |||
外接电源 | +15~24VDC | |||
使用的温度因素规模 | 5~50℃ (Recommended Temperature Range : 15~35℃) | |||
加温时刻 | 15 min (Accuracy Guaranteed : 30min) | |||
